Frameset
Frame: Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disc, 700x35 max tyre, BB386 EVO, Mahle X20 AMC plug.
Fork: Gain OMR carbon fork, 700x35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1
Steerer Tube: FSA 1-1/2" Integrated Aluminium Cup
Ebike
Battery: Mahle iX350 36V 353Wh
Range Extender: N/A
Motor: Mahle motor hub X20, ALC
Display: Mahle Pulsar One monochrome ANT+ LEV
Charger: Mahle Active Charger up to 4A
Remote: Mahle ONE Head Unit (BT/ANT+)
Drivetrain
Crankset: Shimano 105 R7100 34x50t
Shifters: Shimano R7120
Cassette: Shimano 105 R7100 11-34t 12-Speed
Rear Derailleur: Shimano 105 R7100
Front Derailleur: Shimano 105 R7100
Chain: Shimano M6100
Cockpit & Brakes
Handlebar: OC Road Performance RP21 Alu SL, Reach 80, Drop 125
Stem: OC Road Performance RP10, -8º
Brakes: Shimano R7170 Hydraulic Disc
Rotors: N/A
Brakes Configuration: N/A
Wheels & Tyres
Wheels: Alloy, Tubeless, 700c, 21c
Tyres: Pirelli P ZERO™ Race X SmartEVO TLR 700x30c
Front Wheel Axle: Orbea Thru Axle 12x100mm M12x2 P1 Lite
Rear Wheel Axle: Orbea Thru Axle 12x142mm M12x2 P1 Lite
Components
Seatpost: OC Performance XP10-S Carbon, 27.2mm, Setback 20
Saddle: Fizik Aliante R5
Accessories
Front Light: Front position light, on display holder, COB Led, On/Off, 60 Lumen, ECE50.
Rear Light: Rear position light, on saddle clamp, COB Led, On/Off, 12 Lumen. STVZO
Handlebar Tape: Orbea Anti-Slippery/Shock Proof
