*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: 800 Series OCLV Carbon, TQ drive system, tapered head tube, rear IsoSpeed, internal routing, flat mount disc, mudguard mounts, 142x12 mm thru axle
Fork: Domane+ carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat mount disc, 12x100 mm thru axle
Weight
Weight: 56 – 12.85 kg / 28.33 lb (with TLR sealant, no tubes)
Weight limit: 125 kg (275 lb)
E-system
Battery: TQ 360Wh
Charger: TQ 4A charger
Computer: TQ LED display with Bluetooth & ANT+ connectivity
Motor: TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power
Drivetrain
Front derailleur: Shimano 105 R7150 Di2, braze-on, down swing
Rear derailleur: Shimano 105 R7150 Di2, 36T max cog
*Crank:
Size: 50, 52 – Praxis Carbon, 165 mm length
Size: 54, 56 – Praxis Carbon, 170 mm length
Size: 58, 60, 62 – Praxis Carbon, 172.5 mm length
Chainring: Praxis, 50/34T, 12-speed
Cassette: Shimano 105 7101, 11-34, 12-speed
Chain: Shimano SLX M7100, 12-speed
Max. chainring size: 1x: 46T, 2x: 52/36
Wheels
Wheel front: Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle
Wheel rear: Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, Shimano 11/12-speed freehub, 142x12 mm thru axle
Tyre: Bontrager Kwaremont Pro TLR, tubeless ready, folding bead, Race Dual-Compound, 120 tpi, 700x32 mm
Tyre part: Bontrager TLR sealant, 180 ml/6 oz
Max tyre size: 40 mm without mudguards, 35 mm with mudguards
Components
Saddle: Verse Short Comp, steel rails, 145 mm width
*Seatpost:
Size: 50, 52, 54, 56 – KVF aero carbon seat post, 20 mm offset, 280 mm length
Size: 58, 60, 62 – KVF aero carbon seat post, 20 mm offset, 320 mm length
*Handlebar:
Size: 50, 52 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width
Size: 54, 56 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width
Size: 58, 60, 62 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width
Handlebar tape: Bontrager Supertack Perf tape
*Stem:
Size: 50 – Trek RCS Pro, -7-degree, 80 mm length
Size: 52, 54 – Trek RCS Pro, -7-degree, 90 mm length
Size: 56, 58 – Trek RCS Pro, -7-degree, 100 mm length
Size: 60, 62 – Trek RCS Pro, -7-degree, 110 mm length
Brakes
Brake rotor: Shimano RT70, CentreLock, 160 mm
Rotor size: Max brake rotor sizes: 180 mm front, 160 mm rear
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
