Frameset
Frame: Orbea Orca carbon OMR 2026, monocoque construction, HS 1.5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, internal cable routing.
Fork: Orbea Orca OMR ICR 2024, full carbon, 1-1/8" - 1.5" tapered head tube compatible, Thru axle 12x100mm, thread M12x2 P1.
Steerer Tube: FSA 1-1/2" Integrated Aluminium Cup
Drivetrain
Crankset: Shimano Ultegra R8100, 34x50T
Shifters: Shimano ST-8170
Cassette: Shimano Ultegra R8100, 11-30T, 12-Speed
Rear Derailleur: Shimano Ultegra Di2 R8150
Front Derailleur: Shimano Ultegra Di2 R8150
Chain: Shimano M8100
Cockpit
Handlebar: Integrated Bar and Stem OC SH-RA10, Road Aero Carbon, Reach 80, Drop 125
Brakes: Shimano R8170 Hydraulic Disc
Rotors: 160mm Front / 140mm Rear
Brakes Configuration: N/A
Wheels & Tyres
Wheels: Oquo Road Performance RP35TEAM
Tyres: Vittoria Corsa N.Ext G2.0 Foldable 700x28c
Front Wheel Axle: Orbea Thru Axle 12x100mm M12x2 P1 Lite
Rear Wheel Axle: Orbea Thru Axle 12x142mm M12x2 P1 Lite
Components
Seatpost: OC Performance XP10-S Carbon, 27.2mm, Setback 20
Saddle: Fizik Vento Antares R7 Alloy Rail, 140mm
Accessories
Handlebar Tape: Orbea Anti-Slippery/Shock Proof
Storage: OC Toolbox TB02PP
