*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: 800 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, mudguard mounts, flat mount disc, 142x12mm thru axle
Fork: Domane SLR carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, carbon dropouts, 12x100 mm thru axle
Weight limit: 125 kg (275 lb)
E-system
Battery: Shimano BT-DN300
Charger: Charging cable included
Drivetrain
Shifter: Shimano Dura-Ace R9270 Di2, 12-speed
Front derailleur: Shimano Dura-Ace R9250 Di2, braze-on, down swing
Rear derailleur: Shimano Dura-Ace R9250 Di2, 34T max cog
*Crank:
Size:47, 50 – Shimano Dura-Ace R9200, 50/34, 165 mm length
Size:52, 54, 56 – Shimano Dura-Ace R9200, 50/34, 170 mm length
Size:58, 60, 62 – Shimano Dura-Ace R9200, 50/34, 172.5 mm length
Bottom bracket: Praxis, T47 threaded, internal bearing
Cassette: Shimano Dura-Ace R9200, 11-34, 12-speed
Chain: Shimano Dura-Ace/XTR M9100, 12-speed
Max. chainring size: 1x: 48T, 2x: 52/36
Wheels
Wheel front: Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51mm rim depth, 100x12mm thru axle
Wheel rear: Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51mm rim depth, Shimano 11/12 freehub, 142x12mm thru axle
Skewer front: Bontrager Switch thru-axle, removable lever
Skewer rear: Bontrager Switch thru-axle, removable lever
Tyre: Bontrager Kwaremont RSL, tubeless ready, folding bead, dual compound, 320 tpi, 700x32 mm
Tyre part: Bontrager TLR sealant, 180 ml/6 oz
Max tyre size: 38 mm without mudguards, 35 mm with mudguards
Components
Saddle: Verse Short Pro, carbon rails, 145 mm width
*Seatpost:
Size:47-56 – KVF aero carbon seat post, 20 mm offset, 280 mm length
Size:58-62 – KVF aero carbon seat post, 20 mm offset, 320 mm length
*Handlebar:
Size:47 – Bontrager Aero Pro, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop, 38 cm width
Size:50, 52 – Bontrager Aero Pro, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop, 40 cm width
Size:54, 56, 58 – Bontrager Aero Pro, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop, 42 cm width
Size:60, 62 – Bontrager Aero Pro, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop, 44 cm width
Handlebar tape: Trek EcoTack
*Stem:
Size:47 – Trek RCS Pro, -7-degree, 70 mm length
Size:50 – Trek RCS Pro, -7-degree, 80 mm length
Size:52,54 – Trek RCS Pro, -7-degree, 90 mm length
Size:56,58 – Trek RCS Pro, -7-degree, 100 mm length
Size:60,62 – Trek RCS Pro, -7-degree, 110 mm length
Brakes
Brake rotor: Shimano CL900, CentreLock, 160 mm
Rotor size: Max brake rotor sizes: 160 mm front and rear
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
